ETM Inc-Electronic Hardware, Handles, Standoffs

Products Info

Description

Matreial Description	Code
Matreial Description	Round	Square	Hex
Carbon Steel	MS1	MS2	MS3
300 Series Stainless Steel	MSS1	MSS2	MSS3
Aluminum	MA1	MA2	MA3
Brass	MB1	MB2	MB3
Nylon	MN1	MN2	MN3

Code	Thread	Inside hole Dia. +.010 -.000
0	0-80	.640
2	2-56	.090
4	4-40	.115
6	6-32	.140
8	8-32	.166
10	10-32	.192
12	12-24	.218
1/4	1/4-20	.252
5/16	5/16-18	.315
3/8	3/8-16	.380
7/16	7/16-14	.440
1/2	1/2-20	.505

Finish Description	Code
Nickel Plate	S1
Chrome Plate	S2
Satin Chrome	S6
Zinc Plate	S10
Zinc Yellow Chromate	S11
No Finish	S14
Black Oxide	S22
Black Zinc	S23
Passivate	SB5
Anodize Clear	SA1
Glossy Anodize Clear	SA2
Anodize Black	SA3
Glossy Anodize Black	SA4
Clear Iridite	SA5

Part No.	Length	Part No.	Length	Part No.	Length
AS- 3401	1/16	AS- 3443	23/32	AS- 348	1-3/8
AS- 3402	5/64	AS- 3444	47/64	AS- 3486	1-25/64
AS- 3403	3/32	AS- 3445	3/4	AS- 3487	1-13/32
AS- 3404	7/64	AS- 3446	49/64	AS- 3488	1-27/64
AS- 3405	1/8	AS- 3447	25/32	AS- 3489	1-7/16
AS- 3406	9/64	AS- 3448	51/64	AS- 3490	1-29/64
AS- 3407	5/32	AS- 3449	13/16	AS- 3491	1-15/32
AS- 3408	11/64	AS- 3450	53/64	AS- 3492	1-31/64
AS- 3409	3/16	AS- 3451	27/32	AS- 3493	1-1/2
AS- 3410	13/64	AS- 3452	55/64	AS- 3494	1-33/64
AS- 3411	7/32	AS- 3453	7/8	AS- 3495	1-17/32
AS- 3412	15/64	AS- 3454	57/64	AS- 3496	1-35/64
AS- 3413	1/4	AS- 3455	29/32	AS- 3497	1-9/16
AS- 3414	17/64	AS- 3456	59/64	AS- 3498	1-37/64
AS- 3415	9/32	AS- 3457	15/16	AS- 3499	1-19/32
AS- 3416	19/64	AS- 3458	61/64	AS- 34100	1-39/64
AS- 3417	5/16	AS- 3459	31/32	AS- 34101	1-5/8
AS- 3418	21/64	AS- 3460	63/64	AS- 34102	1-41/64
AS- 3419	11/32	AS- 3461	1	AS- 34103	1-21/32
AS- 3420	23/64	AS- 3462	1-1/64	AS- 34104	1-43/64
AS- 3421	3/8	AS- 3463	1-1/32	AS- 34105	1-11/16
AS- 3422	25/64	AS- 3464	1-3/64	AS- 34106	1-45/64
AS- 1823	13/32	AS- 3465	1-1/16	AS- 34107	1-23/32
AS- 1824	27/64	AS- 3466	1-5/64	AS- 34108	1-47/64
AS- 1825	7/16	AS- 3467	1-3/32	AS- 34109	1-3/4
AS- 1826	29/64	AS- 3468	1-7/64	AS- 34110	1-3/4
AS- 1827	15/32	AS- 3469	1-1/8	AS- 34111	1-25/32
AS- 1828	31/64	AS- 3470	1-9/64	AS- 34112	1-51/64
AS- 1829	1/2	AS- 3471	1-5/32	AS- 34113	1-13/16
AS- 1830	33/64	AS- 3472	1-11/64	AS- 34114	1-53/64
AS- 1831	17/32	AS- 3473	1-3/16	AS- 34115	1-27/32
AS- 1832	35/64	AS- 3474	1-13/64	AS- 34116	1-55/64
AS- 1833	9/16	AS- 3475	1-7/32	AS- 34117	1-7/8
AS- 1834	37/64	AS- 3476	1-15/64	AS- 34118	1-57/64
AS- 1835	19/32	AS- 3477	1-1/4	AS- 34119	1-29/32
AS- 1836	39/64	AS- 3478	1-17/64	AS- 34120	1-59/64
AS- 1837	5/8	AS- 3479	1-9/32	AS- 34121	1-15/16
AS- 1838	41/64	AS- 3480	1-19/64	AS- 34122	1-61/64
AS- 1839	21/32	AS- 3481	1-5/16	AS- 34123	1-31/32
AS- 1840	43/64	AS- 3482	1-21/64	AS- 34124	1-63/64
AS- 1841	11/16	AS- 3483	1-11/32	AS- 34125	2
AS- 1842	45/64	AS- 3484	1-23/64
