Products Info

Description

Cpative Panel Screw	Code
Style 1	CPS1
Style 2	CPS2
Style 3	CPS3
Style 4	CPS4
Style 5	CPS5
Style 6	CPS6
Style 7	CPS7

Material Description	Code
Brass	B
Carbon Steel	S
300 Series Stainless Steel	SS

Finish Description	Code
Nickel Plate	S1
Chrome Plate	S2
Satin Chrome	S6
Zinc Plate	S10
Zinc Yellow Chromate	S11
Black Oxide	S22
Black Zinc	S23
Tin Plated	S24
No Finish	S14
Passivate	SB5

Part No.	Thread	Panel	A +.015 -.000	B +.015 -.000	C +.015 -.000	D +.015 -.000	E +.015 -.000	F +.015 -.000	S +.015 -.000
PSR6-440062	4-40	.052-.067	1/4	.188	.150	1/4	.161	.188	.062
PSR6-440093	4-40	.084-.099	1/4	.188	.150	1/4	.161	.156	.093
PSR6-440125	4-40	.109-.140	1/4	.188	.150	1/4	.161	.125	.125
PSR6-632062	6-32	.109-.140	1/4	.188	.150	5/16	.210	.250	.062
PSR6-632093	6-32	.084-.099	1/4	.188	.150	5/16	.210	.218	.093
PSR6-632125	6-32	.109-.140	1/4	.188	.150	5/16	.210	.187	.125
PSR6-632187	6-32	.171-.203	1/4	.188	.150	5/16	.210	.125	.187
PSR6-832062	8-32	.052-.067	3/8	.218	.188	5/16	.210	.250	.062
PSR6-832093	8-32	.084-.099	3/8	.218	.188	5/16	.210	.218	.093
PSR6-832125	8-32	.109-.140	3/8	.218	.188	5/16	.210	.187	.125
PSR6-832187	8-32	.171-.203	3/8	.218	.188	5/16	.210	.125	.187
PSR6-1024062	10-24	.052-.067	3/8	.270	.228	3/8	.236	.312	.062
PSR6-1024093	10-24	.084-.099	3/8	.270	.228	3/8	.236	.281	.093
PSR6-1024125	10-24	.109-.140	3/8	.270	.228	3/8	.236	.250	.125
PSR6-1024187	10-24	.171-.203	3/8	.270	.228	3/8	.236	.188	.187
PSR6-1024250	10-24	.234-.265	3/8	.270	.228	3/8	.236	.125	.250
PSR6-1032062	10-32	.052-.067	3/8	.270	.228	3/8	.236	.312	.062
PSR6-1032093	10-32	.084-.099	3/8	.270	.228	3/8	.236	.281	.093
PSR6-1032125	10-32	.109-.140	3/8	.270	.228	3/8	.236	.250	.125
PSR6-1032187	10-32	.171-.203	3/8	.270	.228	3/8	.236	.188	.187
PSR6-1032250	10-32	.234-.265	3/8	.270	.228	3/8	.236	.125	.250
PSR6-1224062	12-24	.052-.067	3/8	.270	.228	3/8	.239	.312	.062
PSR6-1224093	12-24	.084-.099	3/8	.270	.228	3/8	.239	.281	.093
PSR6-1224125	12-24	.109-.140	3/8	.270	.228	3/8	.239	.250	.125
PSR6-1224187	12-24	.171-.203	3/8	.270	.228	3/8	.239	.188	.187
PSR6-1224250	12-24	.234-.265	3/8	.270	.228	3/8	.239	.125	.250
PSR6-1420062	1/4-20	.052-.067	1/2	.356	.295	7/16	.295	.375	.062
PSR6-1420093	1/4-20	.084-.099	1/2	.356	.295	7/16	.295	.343	.093
PSR6-1420125	1/4-20	.109-.140	1/2	.356	.295	7/16	.295	.312	.125
PSR6-1420187	1/4-20	.171-.203	1/2	.356	.295	7/16	.295	.250	.187
PSR6-1420250	1/4-20	.234-.265	1/2	.356	.295	7/16	.295	.187	.250
PSR6-1428062	1/4-28	.052-.067	1/2	.356	.295	7/16	.295	.375	.062
PSR6-1428093	1/4-28	.084-.099	1/2	.356	.295	7/16	.295	.343	.093
PSR6-1428125	1/4-28	.109-.140	1/2	.356	.295	7/16	.295	.312	.125
PSR6-1428187	1/4-28	.171-.203	1/2	.356	.295	7/16	.295	.250	.187
PSR6-1428250	1/4-28	.234-.265	1/2	.356	.295	7/16	.295	.187	.250
PSR6-51624062	5/16-24	.052-.067	1/2	.404	.343	7/16	.297	.375	.062
PSR6-51624093	5/16-24	.084-.099	1/2	.404	.343	7/16	.297	.343	.093
PSR6-51624125	5/16-24	.109-.140	1/2	.404	.343	7/16	.297	.312	.125
PSR6-51624187	5/16-24	.171-.203	1/2	.404	.343	7/16	.297	.250	.187
PSR6-51624250	5/16-24	.234-.265	1/2	.404	.343	7/16	.297	.187	.250
